M4nano
M4nano
M4nano
M4nano

M4nano

M4nano

8 Channel DSP with 4 Channel Class D Amplifier 4 x 55/95 Watts

$769.95 USD
$769.95 USD
Shipping calculated at checkout.
Payment & Security
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

  • Free Nationwide Shipping
  • Free Returns Within 30 days

Downloads

Owner's Manual ↘

Product Overview

Small in size, massive in performance—the MUSWAY M4 Nano redefines what a compact amplifier can do. Engineered with advanced Class D technology, this 4-channel amplifier provides detailed, dynamic sound with minimal heat generation and high efficiency.

The M4 Nano offers flexible installation options thanks to its ultra-compact housing, making it perfect for under-seat mounting or hidden installations. With stable operation at 2 ohms and bridged capability at 4 ohms, it delivers versatile system-building options—whether you're powering component speakers, coaxials, or bridging channels for more output.
M4nano

Product Specifications

Distortion - THD, 1 kHz @ 4 Ω, 5 W:
0.01 %

Bandwidth -3 dB, 2 V/RMS, 4 Ω @ -1 dB:
10 Hz - 22 kHz

S/N ratio @ A weighted, 1 V, Max. Power:
100 dB

Damping factor @ 1 kHz, 2 V/RMS, 4 Ω:

75

Input Sensitivity:
3 - 24 V/RMS (high-level)
0.7 - 6 V RMS (low-level)

Input Impedance:
18 Ω (high-level)

Load Impedance (Min.):
4 CH @ 2 Ω
2 CH bridged @ 4 Ω

Output Power RMS @13.8 VDC, 1% THD:
4 x 55/95 Watts @ 4/2 Ω
2 x 200 Watts bridged @ 4 Ω

Output Power RMS @ 14.4 VDC, 1% THD:
4 x 60/100 Watts @ 4/2 Ω
2 x 220 Watts bridged @ 4 Ω

Product Description

The MUSWAY M4 Nano is an ultra-compact 4-channel Class D amplifier designed to deliver impressive power and clarity in the smallest possible footprint. Built for modern vehicles with limited installation space, the M4 Nano combines high efficiency, low distortion, and dynamic output performance—making it ideal for OEM upgrades or custom audio builds.
